ABB System Pro M Compact S200 MCB, 3P, 20A Curve D, 440V AC, 12V DC, 6 kA Breaking Capacity
Τεχνικό φυλλάδιο
Προδιαγραφές
Brand
ABBNumber of Poles
3P
Current Rating
20A
Tripping Characteristics
Type D
Rated AC Voltage
440V
Rated DC Voltage
12V
Breaking Capacity at Maximum Voltage Rating
6 kA
Range
System Pro M Compact
Series
S200
Circuit Breaker Type
MCB
Width
52.5mm
Length
88mm
Mounting Style
DIN Rail Mount
Depth
69mm
Model Number
S203-D20
Better World Product (Find out more)
Yes
Better World Claim
Designed for disassembly
Terminal Contact Type
Screw
Tripping Mechanism
Thermal
Application
Commercial, Industrial
Reset Actuator Type
Toggle Switch
Χώρα Προέλευσης
Germany
Λεπτομέρειες Προϊόντος
Type D Triple Pole 6kA - System pro M Compact
Type D characteristic offers short circuit response (but greater than Type C) of 10-13 x normal rated current, making it ideal for circuits with higher inrush currents such as motor control and fluorescent lighting installations in industrial buildings where nuisance tripping might occur if a faster type was used.
Ημερομηνία αποθέματος προσωρινά μη διαθέσιμη
Παρακαλούμε ελέγξτε ξανά αργότερα.
€ 100,57
Μονάδας (Exc. Vat)Χωρίς Φ.Π.Α
€ 124,71
Μονάδας Με Φ.Π.Α
1
€ 100,57
Μονάδας (Exc. Vat)Χωρίς Φ.Π.Α
€ 124,71
Μονάδας Με Φ.Π.Α
1
Αγοράστε μαζικά
| Quantity Ποσότητα | Τιμή μονάδας |
|---|---|
| 1 - 4 | € 100,57 |
| 5 - 9 | € 97,02 |
| 10 - 24 | € 93,31 |
| 25 - 49 | € 89,43 |
| 50+ | € 85,40 |
Τεχνικό φυλλάδιο
Προδιαγραφές
Brand
ABBNumber of Poles
3P
Current Rating
20A
Tripping Characteristics
Type D
Rated AC Voltage
440V
Rated DC Voltage
12V
Breaking Capacity at Maximum Voltage Rating
6 kA
Range
System Pro M Compact
Series
S200
Circuit Breaker Type
MCB
Width
52.5mm
Length
88mm
Mounting Style
DIN Rail Mount
Depth
69mm
Model Number
S203-D20
Better World Product (Find out more)
Yes
Better World Claim
Designed for disassembly
Terminal Contact Type
Screw
Tripping Mechanism
Thermal
Application
Commercial, Industrial
Reset Actuator Type
Toggle Switch
Χώρα Προέλευσης
Germany
Λεπτομέρειες Προϊόντος
Type D Triple Pole 6kA - System pro M Compact
Type D characteristic offers short circuit response (but greater than Type C) of 10-13 x normal rated current, making it ideal for circuits with higher inrush currents such as motor control and fluorescent lighting installations in industrial buildings where nuisance tripping might occur if a faster type was used.
