Fluke 373 Clamp Meter, Max Current 600A ac CAT III 600V With RS Calibration
Technical Document
Specifications
Brand
FlukeAbsolute Maximum AC Current Measurement
600A ac
Absolute Maximum AC Voltage Measurement
600V ac
Absolute Maximum DC Voltage Measurement
600V dc
Absolute Maximum Resistance Measurement
6kΩ
Model Number
373
Calibrated
RSCAL
AC Current Measurement Resolution
100mA
Clamp Meter Type
AC Current Clamp Meter
Best AC Current Accuracy
±2% +5 digits
Best AC Voltage Accuracy
±1% +5 Digits
Best DC Voltage Accuracy
±1% +5 Digits
Functions Measured
AC Current, AC Voltage, Capacitance, Continuity, DC Voltage, Resistance
True RMS
Yes
Power Source
Battery
Width
85mm
Length
232mm
Resistance Measurement Resolution
100mΩ
Dimensions
232 x 85 x 45mm
DC Voltage Measurement Resolution
100mV
Minimum Operating Temperature
-10°C
Height
45mm
AC Voltage Measurement Resolution
100mV
AC Current Measurement Range
600 A
AC Voltage Measurement Range
600 V
Maximum Conductor Size
32mm
Weight
370g
Safety Category Level
CAT II, CAT IV
Safety Category Voltage
300 V, 600V
Battery Type
AA
Safety Category
CAT III 600 V, CAT IV 300V
Best Resistance Measurement Accuracy
±1% +5 Digits
Display Type
LCD
Maximum Operating Temperature
+50°C
Country of Origin
China
Product details
FLUKE 373 True RMS AC Clamp Meter, 600A AC Maximum Current
Got routine maintenance or electrical troubleshooting on your to-do list? Reach for the 373 AC clamp meter from FLUKE to measure voltage and currents without breaking circuits. It features a large LCD display and backlight making your results easy to read, even in dimly lit environments.
The jaws open wide to accommodate bulky cables up to 32mm in size. True RMS capability means you can rely on top-tier accuracy. To get you up and working immediately, the 373 meter comes with test leads, batteries, and full instructions, all packed into a protective carry case.
Fluke 373 Features:
• Measures AC and DC voltage to 600 V
• Measures resistance
• Ergonomic design for comfortable grip and ease of use
• Bright red and yellow colours for quick identification
• Safety category voltage of 300V and 600V to accommodate a wide range of systems
Applications
• Industrial automation
• Automotive industry
• Telecommunications networks
Can I measure resistance and continuity with this product?
Yes, you can. This product comes with a measurement feature for resistance of up to 6kΩ, as well as continuity detection.
What power source does this clamp meter use?
The unit runs on two standard AA batteries, so you can replace them easily.
Supplied with
• 373 True-RMS AC Clamp Meter
• (1 pair) TL75 test leads
• Soft carrying case
• AA Alkaline Batteries (Installed)
• Quick Reference Guide
€ 627.78
€ 627.78 Each (Exc. Vat)
€ 778.45
€ 778.45 Each (inc. VAT)
Calibration type
RS Calibration
1
€ 627.78
€ 627.78 Each (Exc. Vat)
€ 778.45
€ 778.45 Each (inc. VAT)
Calibration type
RS Calibration
1
