Τεχνικό φυλλάδιο
Προδιαγραφές
Brand
SamtecProduct Type
Pin Header
Series
FTSH
Current
3.4A
Pitch
1.27mm
Number of Contacts
14
Housing Material
Liquid Crystal Polymer
Number of Rows
2
Orientation
Vertical
Shrouded/Unshrouded
Unshrouded
Mount Type
Surface
Connector System
Board-to-Board, Wire-to-Board
Contact Material
Phosphor Bronze
Contact Plating
Gold
Minimum Operating Temperature
-55°C
Row Pitch
1.27mm
Termination Type
Solder
Contact Gender
Male
Maximum Operating Temperature
125°C
Standards/Approvals
No
Λεπτομέρειες Προϊόντος
The Samtec FTSH series is a high reliability header strip has 1.27mm of pitch which has 14 contact. It is having terminal made up of phosphor bronze and the insulator material used is black liquid crystal polymer. The FTSH using 0.25 μm gold plated contac
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Ημερομηνία αποθέματος προσωρινά μη διαθέσιμη
€ 352,95
€ 5,43 Μονάδας (Σε μία ράγα των 65) (Exc. Vat)Χωρίς Φ.Π.Α
€ 437,66
€ 6,733 Μονάδας (Σε μία ράγα των 65) Με Φ.Π.Α
65
€ 352,95
€ 5,43 Μονάδας (Σε μία ράγα των 65) (Exc. Vat)Χωρίς Φ.Π.Α
€ 437,66
€ 6,733 Μονάδας (Σε μία ράγα των 65) Με Φ.Π.Α
Ημερομηνία αποθέματος προσωρινά μη διαθέσιμη
65
| Quantity Ποσότητα | Τιμή μονάδας | Per Ράγα |
|---|---|---|
| 65 - 260 | € 5,43 | € 352,95 |
| 325 - 585 | € 5,12 | € 332,80 |
| 650+ | € 4,93 | € 320,45 |
