Vishay Single Layer Ceramic Capacitor 3.3 nF 40kV dc -20 to 80 % Y5U Dielectric, 715C, Screw 85 °C Max Op. Temp.
Τεχνικό φυλλάδιο
Προδιαγραφές
Brand
VishayCapacitance
3.3nF
Product Type
Single Layer Ceramic Capacitor
Voltage
40kV dc
Mount Type
Screw
Series
715C
Tolerance
-20 to 80 %
Automotive Standard
No
Dielectric
Y5U
Package/Case
0814
Minimum Operating Temperature
-30°C
Height
34.5mm
Diameter
58.4mm
Standards/Approvals
EC, RoHS, IEC 61249-2-21
Suppression Class
Class II
Terminal Type
Screw
Maximum Operating Temperature
85°C
Dissipation Factor
0.02%
Χώρα Προέλευσης
Germany
Λεπτομέρειες Προϊόντος
Vishay 715C Series
Vishay 715C series are a high voltage ceramic disc capacitor with screw terminal mounting in an epoxy coated insulation that offers low inductance and high insulation resistance. The 715C series is suitable for a wide range of applications including industrial, high voltage power supplies, x-ray equipment and welding equipment.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Ημερομηνία αποθέματος προσωρινά μη διαθέσιμη
€ 146,28
€ 146,28 Μονάδας (Exc. Vat)Χωρίς Φ.Π.Α
€ 181,39
€ 181,39 Μονάδας Με Φ.Π.Α
1
€ 146,28
€ 146,28 Μονάδας (Exc. Vat)Χωρίς Φ.Π.Α
€ 181,39
€ 181,39 Μονάδας Με Φ.Π.Α
Ημερομηνία αποθέματος προσωρινά μη διαθέσιμη
1
| Quantity Ποσότητα | Τιμή μονάδας |
|---|---|
| 1 - 1 | € 146,28 |
| 2 - 4 | € 141,11 |
| 5 - 9 | € 132,71 |
| 10 - 24 | € 130,36 |
| 25+ | € 128,92 |
